![]() | Plug the unit into a 30-amp power source | |
![]() | Allow the self-diagnostic function to check the power source: | |
![]() | Power source is correctly wired and safe to use. | |
![]() | Pedestal power – Hot/neutral are reversed. Generator power – Bonding plug is needed (bonding plug available separately). | |
![]() | Hot/ground are reversed. | |
![]() | After 45-60 seconds, the green Output LED on the receptacle will indicate there is “live” power for the RV. | |
![]() | Connect Home power cord into SoftStartUp receptacle. |
*Note: Some SoftStartUp units may not include a Green Output LED.
